Características
– Changeable WAN/LAN ports for flexible network resource allocation
– Multi-bandwidth, enjoys multi-services provided by different ISPs, Up to 4 WAN ports access
– Load Balancing, automatically selects the best line according to the load
– Smaller case for cost-effective solution in the small office or Internet cafes network
What This Product Does
– The TL-R470T+ Load Balance Broadband Router possesses stronger data transmission capacity and stability, cost-efficient for networks in places such as Internet cafes and small offices.
Superior Performance and High Stability
– The router features a network dedicated processor, clocked at 400MHz for powerful processing performance, an internal power supply to allow for long term operation stability, and professional lightning protection design keeps your investments as safe as possible.
Three Changeable LAN/WAN Ports
– The TL-R470T+ features three changeable ports that can be set to either LAN or WAN, allowing the router to support up to four WAN ports to satisfy various Internet access requirements through one device. The router also has an integrated smart load balancing function which automatically selects the most efficient line according to load and bandwidth requirements, providing users with consistent network uptime and reliable Ethernet connectivity.
– By the factory default, TL-R470T+ is set to work in the dual WAN ports mode: port 1 and port 2 are working as WAN ports, while port 3~5 are LAN ports.
Management for a Fluid Networking Experience
– Integrating multiple load balancing strategies, IP and port based bandwidth control, session limit, domain filtering, and IP/MAC address filtering, the TL-R470T+ provides users with a fluid network experience, without lag and connection drops.
Easy to Install and Use
– With user-friendly web-based management, remote management and configuration backup & restore functions, the TL-R470T+ provides many comprehensive features that are easy to deploy and maintain, especially for businesses lacking professional IT staff.
Especificaciones
HARDWARE FEATURES
– Standards and Protocols
– TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS
– Interface
– 1 Fixed Ethernet LAN Port
– 3 Changeable Ethernet WAN/LAN Ports
– Network Media
– EIA/TIA-568 100O STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100O STP (maximum 100m)
– Button: Reset Button
– Dimentions( W x D x H ): 209*126*26 mm
– Power Supply: Internal Universal Power Supply AC100-240V~ 50/60Hz Input
SOFTWARE FEATURES
– WAN Type: Dynamic IP, Static IP, PPPoE, PPTP, L2TP, BigPond Cable
– Basic Function
– MAC Address Modify/Clone, VPN Pass-through
– Static Routing, Dynamic DNS
– Multi-WAN Function
– Detecting Online
– Quality of Service
– Session Limit
– Port Forwarding
– Port Triggering
– DMZ Host
– UPnP
– Dynamic DNS: Dyndns, No-IP, PeanutHull, Comexe
– VPN Pass-Through: PPTP, L2TP, IPsec (ESP)
– Access Control
– Host List, Access Schedule, Rule Management
– Firewall Security
– MAC Address Filtering
– Domain Name Filtering
– DoS Protection
– Management
– Port Mirror
– Restore & Backup Configuration
– Remote Web Management
OTHERS
– Certification: CE, FCC, RoHS
– Package Contents
– Power cord
– RJ-45 Ethernet Cable
– WAN/LAN Ports Configuration Guide
– Resource CD
– Temperature
– Storage: -40°C~70°C (-40°F~158°F)
– Environment
– Storage: 5%~90% RH Non-Condensing
