D-Link Gigabit PoE 802.3af – Inyector Corriente

Simplicity

• Plug-and-Play with no software required
• Easy installation of PoE devices where a power outlet is not available
• Reduces installation and network equipment costs
• Provides power over existing network cabling to PoE devices such as access points, IP cameras and IP phones
• Lightweight and compact
• 802.3af compliant with output PoE power of 0.4 A at 48 V

Gigabit Connectivity

• Power Over Ethernet (PoE) Injector for 10/100/1000T connections delivers power up to 100 metres (328ft)
• Connect your devices at Gigabit speeds, all within a compact device

Technical Specifications

Ports

P + Data Port (out)

• IEEE 802.3af compliant
• Supports half/full-duplex operation
• IEEE 802.3 compliant
• IEEE 802.3u compliant
• IEEE 802.3ab compliant
• 10/100/1000BASE-T port

Data Port (in)

• Supports half/full-duplex operation
• IEEE 802.3 compliant
• IEEE 802.3u compliant
• IEEE 802.3ab compliant
• 10/100/1000BASE-T port

Physical

Dimensions (L x W x H)

• 109.8 x 62.2 x 24.5 mm

Weight

• 65 grams

Power

• Consumption: 19.2 watts max
• Output: 0.4 A at 48 V

Temperature

• Operating: 0 to 50 °C (32 to 122 °F)
• Storage: -20 to 70 °C (-4 to 158 °F)

Humidity

• Operating: 10% to 90% non-condensing
• Storage: 5% to 90% non-condensing

Certifications

• CE
• FCC
• VCCI
• C-Tick
• IC
